Harmony Type

Harmony is one of the core features of the crafting system. Mods can add new harmony types through window.modAPI.actions.addHarmonyType. Use RecipeHarmonyType from afnm-types for the current built-in types.

window.modAPI.actions.addHarmonyType(harmonyType: RecipeHarmonyType, config: HarmonyTypeConfig)

harmonyType: A unique string identifier for your harmony type (e.g., ‘elemental’, ‘temporal’, ‘chaos’). Note, as you are adding new and unknown harmony types you need to tell the compiler this is the case, by ‘casting’ the string to the RecipeHarmonyType ‘elemental’ as RecipeHarmonyType
config: An object containing all configuration for the harmony type:

HarmonyTypeConfig Fields

1. `name` (string, required)

The display name of your harmony type shown to players.

Example: “Elemental Balance”

2. `description` (Translatable, required)

Description explaining the harmony mechanics to players. Accepts a plain string or a translatable value and supports special formatting tags:

<name>text</name> - Highlights important terms
<num>number</num> - Highlights numbers
<li>item</li> - Creates list items
<br/> - Line breaks
Standard HTML like <span style="color: green">text</span>

Example:

description: `Balance the elements to maintain <name>Harmony</name>.
  <br/>
  Each action shifts the elemental balance:
  <li>Support: +<num>2</num> heat, -<num>1</num> cold</li>
  <li>Refine: +<num>2</num> cold, -<num>1</num> heat</li>`

3. `processEffect` (function, required)

Called once per crafting technique execution, after the technique’s effects have been applied. Use this to implement per-technique harmony mechanics.

Function Signature:

processEffect: (
  harmonyData: HarmonyData,
  technique: CraftingTechnique,
  progressState: ProgressState,
  entity: CraftingEntity,
  state: CraftingState,
  actionResolution?: CraftingActionResolution
) => void

Parameters:

harmonyData: Store custom data for your harmony type here, in the additionalData field.
technique: The crafting action that was just executed
progressState: Current crafting progress (completion, perfection, harmony, etc.)
entity: The player’s crafting entity with stats and buffs
state: Overall crafting state including the log
actionResolution: Optional details of the resolved crafting action; check for undefined before reading it

Common Operations:

Initialize custom data in harmonyData.additionalData. e.g. harmonyData.additionalData = { heat: 0, cold: 0 }
Modify progressState.harmony based on player actions
Add/remove buffs to entity.buffs
Log messages to state.craftingLog
Set harmonyData.recommendedTechniqueTypes to guide the player on the best crafting action types to use next (if relevant)

4. `onBarChange` (function, optional)

Fired after every individual completion or perfection change during a technique’s execution. Use this for per-instance reactions, such as scoring harmony rewards or penalties each time a bar moves, rather than once at end of turn. Omit if your harmony only cares about end-of-turn state.

Function Signature:

onBarChange?: (
  bar: 'completion' | 'perfection',
  harmonyData: HarmonyData,
  progressState: ProgressState,
  entity: CraftingEntity,
  state: CraftingState
) => void

Parameters:

bar: Which bar changed ('completion' or 'perfection')
harmonyData: Your harmony type’s data object (same as in processEffect)
progressState: Current crafting progress
entity: Player’s crafting entity
state: Overall crafting state

Example — scoring per-bar instead of per-technique:

onBarChange: (bar, harmonyData, progressState, entity, state) => {
  // Award +5 harmony each time the focused bar rises
  const data = harmonyData.additionalData as { focusedBar: 'completion' | 'perfection' };
  if (bar === data.focusedBar) {
    progressState.harmony += 5;
    state.craftingLog.push('Eccentric Decree: focused bar advanced. +5 harmony');
  } else {
    progressState.harmony -= 5;
    entity.stats.pool -= 5;
    state.craftingLog.push('Eccentric Decree: other bar advanced. -5 harmony, -5 Qi Pool');
  }
},

5. `initEffect` (function, required)

Called once when crafting begins to initialize your harmony type.

Function Signature:

initEffect: (harmonyData: HarmonyData, entity: CraftingEntity) => void

Common Operations:

Initialize your custom data structure in harmonyData.additionalData
Apply starting buffs to the entity
Set initial recommended techniques

6. `renderComponent` (function, required)

Returns a React component to display your harmony’s visual state during crafting.

Function Signature:

renderComponent: (harmonyData: HarmonyData) => ReactNode

Guidelines:

Component should be positioned absolutely within the crafting interface
Use Box components with proper positioning
Access your custom data from harmonyData.additionalData
Return visual feedback showing current state
Can draw custom assets to be rendered, by drawing them on a blank image using the base cauldron background (below) as a guide. Do not include the cauldron itself in your new asset, simply use it as a guide for the image size and positioning of your new asset.

Required display and progression fields

Also supply shortDescription, icon (a Material UI SVG icon component), iconColour, iconBorderColour, complexityMultiplier, unlockFlag, and statTable. The unlock flag controls whether players can select the harmony; set it through your teaching quest. statTable contains optional generators for clothing, talisman, artefact, cauldron, and mount stats.

HarmonyData.additionalData is unknown; narrow or cast it to your mod’s data shape before reading its fields.

Optional cost and starting harmony overrides

qiCostMultiplier and stabilityCostMultiplier receive (technique: CraftingTechnique, harmonyData: HarmonyData) and return a numeric multiplier for the action’s live resource cost. For example, returning 0.5 halves the cost. These callbacks affect the displayed cost and the amount spent by the engine.

startingHarmony sets the initial harmony value for this harmony type. Omit it to use the default starting value.

Complete Example

Save this JSX example in a .tsx file and import it from src/modContent/index.ts. The styles use MUI 9’s sx prop, and the icon comes from the package root to use the game’s shared icon runtime.

import type { HarmonyData, RecipeHarmonyType } from 'afnm-types';
import { Box, Typography } from '@mui/material';
import { LocalFireDepartment } from '@mui/icons-material';

// This example stores only numeric fire/water levels in additionalData.
function elementData(harmonyData: HarmonyData): { fire: number; water: number } {
  return (harmonyData.additionalData ??= { fire: 5, water: 5 }) as { fire: number; water: number };
}

window.modAPI.actions.addHarmonyType('elemental' as RecipeHarmonyType, {
  name: 'Elemental Balance',
  shortDescription: 'Balance fire and water to gain harmony.',
  icon: LocalFireDepartment,
  iconColour: '#f44336',
  iconBorderColour: '#2196f3',
  complexityMultiplier: 1,
  unlockFlag: 'elemental_harmony_unlocked',
  statTable: { clothing: quality => ({ power: quality }) },

  description: `Balance fire and water elements to maintain <name>Harmony</name>.
    <br/>
    <br/>
    Actions affect element levels:
    <li>Fusion: +<num>3</num> fire</li>
    <li>Refine: +<num>3</num> water</li>
    <li>Support/Stabilize: +<num>1</num> to lower element</li>
    <br/>
    Perfect balance (both at 5): +<num>15</num> <name>Harmony</name>
    <br/>
    Imbalance: -<num>10</num> <name>Harmony</name> per point of difference`,

  processEffect: (harmonyData, technique, progressState, entity, state) => {
    // Initialize data if needed
    harmonyData.additionalData = harmonyData.additionalData || {
      fire: 5,
      water: 5
    };

    const data = elementData(harmonyData) as { fire: number; water: number };

    // Process technique effects
    if (technique.type === 'fusion') {
      data.fire = Math.min(10, data.fire + 3);
      state.craftingLog.push(`Fire element increased to ${data.fire}`);
    } else if (technique.type === 'refine') {
      data.water = Math.min(10, data.water + 3);
      state.craftingLog.push(`Water element increased to ${data.water}`);
    } else {
      // Support/Stabilize boost the lower element
      if (data.fire < data.water) {
        data.fire += 1;
      } else {
        data.water += 1;
      }
    }

    // Calculate harmony based on balance
    const diff = Math.abs(data.fire - data.water);
    if (diff === 0 && data.fire === 5) {
      progressState.harmony += 15;
      state.craftingLog.push(`Perfect balance! +15 harmony`);
    } else {
      progressState.harmony -= diff * 10;
      state.craftingLog.push(`Imbalance penalty: -${diff * 10} harmony`);
    }

    // Apply buffs based on dominant element
    if (data.fire > data.water) {
      entity.buffs = [{
        name: 'Fire Dominance',
        icon: 'flame.png',
        canStack: false,
        stats: {
          intensity: { value: 0.3, stat: 'intensity' }
        },
        effects: [],
        onFusion: [],
        onRefine: [],
        stacks: 1,
        displayLocation: 'none'
      }, ...entity.buffs.filter(b => b.name !== 'Fire Dominance' && b.name !== 'Water Dominance')];
    } else if (data.water > data.fire) {
      entity.buffs = [{
        name: 'Water Dominance',
        icon: 'water.png',
        canStack: false,
        stats: {
          control: { value: 0.3, stat: 'control' }
        },
        effects: [],
        onFusion: [],
        onRefine: [],
        stacks: 1,
        displayLocation: 'none'
      }, ...entity.buffs.filter(b => b.name !== 'Fire Dominance' && b.name !== 'Water Dominance')];
    }

    // Recommend techniques to balance
    if (data.fire > data.water + 2) {
      harmonyData.recommendedTechniqueTypes = ['refine'];
    } else if (data.water > data.fire + 2) {
      harmonyData.recommendedTechniqueTypes = ['fusion'];
    } else {
      harmonyData.recommendedTechniqueTypes = ['support', 'stabilize'];
    }
  },

  initEffect: (harmonyData, entity) => {
    harmonyData.additionalData = {
      fire: 5,
      water: 5
    };
    harmonyData.recommendedTechniqueTypes = ['fusion', 'refine'];
  },

  renderComponent: (harmonyData) => {
    const { fire, water } = elementData(harmonyData);

    return (
      <Box
        id="elemental"
        sx={{ display: 'flex', mt: 5.2, position: 'relative', justifyContent: 'center' }}
      >
        {/* Fit to the bounds of the cauldron */}
        <Box
          sx={{
            width: 'calc(min(35vw, 35vh))',
            height: 'calc(min(35vw, 35vh))',
            position: 'relative',
            overflow: 'visible',
          }}
        >
          <Box
            sx={{
              display: 'flex',
              position: 'absolute',
              zIndex: 21,
              top: 0,
              left: 0,
              width: '100%',
              height: '100%',
            }}
          >
            {/* Fire meter */}
            <Box
              sx={{
                flex: 1,
                display: 'flex',
                flexDirection: 'column',
                alignItems: 'center',
                position: 'absolute',
                zIndex: 21,
                top: 0,
                left: 0,
                width: '100%',
                height: '100%',
              }}
            >
              <Typography sx={{ color: 'red' }}>Fire: {fire}</Typography>
              <Box
                sx={{
                  width: '30px',
                  height: '60px',
                  bgcolor: 'rgba(255,0,0,0.2)',
                  border: '1px solid red',
                  position: 'relative',
                }}
              >
                <Box
                  sx={{
                    position: 'absolute',
                    bottom: 0,
                    width: '100%',
                    height: `${fire * 10}%`,
                    bgcolor: 'red',
                  }}
                />
              </Box>
            </Box>

            {/* Water meter */}
            <Box
              sx={{
                flex: 1,
                display: 'flex',
                flexDirection: 'column',
                alignItems: 'center',
                position: 'absolute',
                zIndex: 21,
                top: 0,
                right: 0,
                width: '100%',
                height: '100%',
              }}
            >
              <Typography sx={{ color: 'blue' }}>Water: {water}</Typography>
              <Box
                sx={{
                  width: '30px',
                  height: '60px',
                  bgcolor: 'rgba(0,0,255,0.2)',
                  border: '1px solid blue',
                  position: 'relative',
                }}
              >
                <Box
                  sx={{
                    position: 'absolute',
                    bottom: 0,
                    width: '100%',
                    height: `${water * 10}%`,
                    bgcolor: 'blue',
                  }}
                />
              </Box>
            </Box>
          </Box>
        </Box>
      </Box>
    );
  },
});

Assigning a Harmony Type

Set harmonyTypeOverride on an individual recipe to use your registered harmony type. Define baseRecipe as a complete RecipeItem first.

const elementalRecipe: RecipeItem = {
  ...baseRecipe, // A complete RecipeItem defined earlier; override its harmony below
  harmonyTypeOverride: 'elemental' as RecipeHarmonyType,
}

Best Practices

Balance Risk/Reward: Higher harmony bonuses should require more skill or risk
Clear Visual Feedback: Your render component should clearly show the current state
Informative Logging: Use state.craftingLog.push() to explain what is happening
Buff Management: Always filter out old buffs before applying new ones with the same name
Recommended Techniques: Use harmonyData.recommendedTechniqueTypes to guide players
Per-bar Reactions: Use onBarChange when you need to react to individual bar changes, not just end-of-turn state

Utility Functions

Common utilities available in harmony implementations:

// Colour formatting for logs
const col = (content, color) => `<span style="color: ${color}">${content}</span>`;

// Technique type formatting
const fusion = `<span style="color: lime">Fusion</span>`;
const refine = `<span style="color: cyan">Refine</span>`;
const support = `<span style="color: #eb34db">Support</span>`;
const stabilize = `<span style="color: orange">Stabilize</span>`;
